All In One Lead Carbon ESS
Tianneng lead-carbon energy storage machine products TNAiO-1022-AL0210S2, TNAiO-1522-AL0210S1, TNAiO-2522-AL0315S1 is a household energy storage products, integrated design, Lead-acid/Lead carbon two battery types optional, intelligent digital energy storage equipment, suitable for sunny, power unstable areas, the product has a very cost-effective, easy to install and use, very suitable for household backup power use, welcome global partners to purchase!
Product Feature
Tianneng household energy storage products have excellent performance, and consumers have a good sense of experience.
All in one design
Integrated design of built-in MPPT and battery.Diversified batteries are available: lead-acid/lead-carbon.
Rich interface
Two 5V/3A, two 12V/2A, which can meet the power supply requirements of different DC devices.Type C 5V/3A and Type C-100W special interface for high-power equipment.
Automatic control
Fully automatic control and management function, large-size dot-matrix LCD display, rich user setting interface, real-time monitoring system parameters.
Plug And Play
The on-site operation is simple, the installation is convenient, and the labor cost is effectively saved.
Technical Atlas
Product Specification
| Module | TNAiO-1022-AL0210S2 | TNAiO-1522-AL0210S1 | TNAiO–2522-AL0315S1 |
|---|---|---|---|
| Rated Utility work voltage | 220VAC | ||
| Utility work voltage range | 176VAC~285VAC | ||
Utility input frequency range | 45Hz-65Hz | ||
Max.Utility work current (Charging+Bypass | 2.2A for charging+4.5A for bypass@220VA | 2.8A for charging+6.8A for bypass@220VAC | 3.5A for charging+11.4A for bypass@220VAC |
| Utility transfer time | Utility bypass to lnverter output:<10ms Inverter output to Utility bypass: Oms | ||
| AC input overload relay | YES | ||
| Rated output power(@25°C) | 1000W | 1500W | 2500W |
| Surge output power(5s) | 1500W | 2000W | 4000W |
| Rated output voltage | 220VAC土3% | ||
| Rated output frequency | 50Hz/60Hz士0.2% | ||
| Output wave | Pure sine wave | ||
| Output distortion THD | ≤3%(Resistive load) | ||
| Output soft start | HAVE | ||
